Kevin of Steel Frameset
Kevin of Steel Frameset
Couldn't load pickup availability
Enquire
Enquire
For info on availability, please contact sales@curvecycling.com,
call us on 03 9088 0274.
Alternatively, Enquire Now.
Geometry
Geometry
You can find geometry charts for all our current frame models HERE.
Shipping
Shipping
Free International Shipping for all Framesets, Complete Bikes, Forks, Wheelsets, Bars and Rocket Pooches is included in the sales price (*excludes Belgie DISC Ultegra)
All other products are subject to shipping charges calculated at checkout. See our Shipping Policy for further details.
FAQs
FAQs
Check HERE for further info regarding custom paint, bike set up and more.
| I want to attach bags. What will it do to the frame finish? |
Curve's steel frames are finished with high-quality and durable paint, but the paint is not unaffected by rubbing from bike bags or rock strikes etc. If you want to keep your paint looking pristine, we recommend that you use some kind of protective film - especially in the high-wear areas where bag straps are in direct contact with the frame. Stock Ti frames are not painted, but bag rub will affect the surface finish. The lighter, brushed, finish can be refreshed using a fine abrasive pad, but the darker blasted finish can only be refinished by media blasting. To keep your Ti frame looking pristine, we recommend using protective film. |
| I want to get a custom frame bag made. Can you give me the frame dimensions? | Of course! Have a look at our bagmaker page HERE where you can download full-scale PDFs showing the internal dimensions of all our frame models. |
Italian Steel -
The main frame triangle is comprised of Italian-made double-butted Columbus Zona tubing. Zona allows for the ideal compromise between weight, strength and life of the frame.
Two Bikes In One -
The GXR's carbon fork, the Ride 400, has clearance for wheel options based on your riding style. For example, Kevin can run either 700c wheels with 32–45 mm tyres, best suited for commuting, gravel, and cyclocross, or if you’re looking to tackle some rougher terrain with more traction, use 650b (27.5”) wheels fitted with 1.8–2.2” tyres. Curve has the above wheel options in both carbon and aluminium available.
Big Tyre Clearance -
The custom 4130 steel yoke design allows Kevin to run wide gravel tyres in two wheel sizes without tyre rub. Up to 45mm for 700c, and around 2.2"/55mm for 27.5"/650b. Clearance may vary depending on your choice of tyre tread.
Ready For Adventure -
Kevin comes equipped with rear rack mounts, fender mounts, and 3 x bidon mounts; and can run either a 1x or 2x* drivetrain. Kevin is ready for light single or multi-day bikepacking adventures thanks to generous tyre clearance and balanced geometry that produces a stable riding platform.
Want to Carry More?
With a wide range of frame and fork mounted rack systems on the market, and with more appearing every week, it is important to understand which rack systems are compatible with your Curve frame and fork, and how to mount them correctly in order to ensure safe riding, avoid damage and voiding your warranty. Before mounting a rack, we strongly recommend you get in touch with us to confirm compatibility and the correct mounting procedure. This will minimise the risk of injury, product damage and voiding your warranty. Your local Curve dealer, or the team at Curve HQ, can also help you select a rack system and mount it to your bike for you.
There is ample room for bikepacking bags on all frameset sizes. To make sure current, prospective or custom bagging fits your frame size please see our Bagmaker Drawing page.
* A "lowering" braze-on adapter may be needed to fit a front derailleur without interfereing with the bottle bosses. Contact us for info.
| Frame | Curve GXR - Columbus Zona & 4130 Chromoly |
| Fork | Ride 400 Carbon Fork |
| Headset | Curve 44 mm semi-internal |
| Seatclamp | Curve 29.8 Black Alloy |
| Thru-Axles | 12 x 100 Front, 12 x 142 Rear |
| Other |
Curve Cocky head badge, 6 x double cable guides (get in touch for optional triple cable guides for 2x setups), and spare derailleur hanger Weight: approx. 2400g for size MD (frame only) |
If you are building your Curve frameset with a self-supplied groupset, please see the specification guid via the link below to ensure the necessary parts are sufficiently compatible with our framesets.
The specification details may change over time. Please check HERE for the latest version.
Collapsible content
Frameset Specifications for Self-Supplied Groupsets
Customer Reviews
my Kevin of Steel has landed and I just wanted to let you, the Kev-curious, know it is freaking awesome! I've had carbon road bikes and alloy city bikes recently and can attest that what they say about steel is real - buttery smooth! I added the dirt hoops last week after a couple of weeks rolling on loaner alloy rims and immediately noticed the faster pickup on the hills when I stand up to stomp on the pedals. Looking forward to summer and attacking a few gravel events and a cheeky brevet or two!
thanks again Curve team for creating my new forever bike!
